Wednesday, April 26, 2006

MySQL Community Awards

Second day of the MySQL USers Conference 2006.
At breakfast, Arjen approached me, asking if I could hang nearby the podium during the keynote. "You may end up on stage", he said. I thought that they were going to hand me the iPod that was announced some time ago. So I went there and secured a seat as close as I could, together with Markus, Beat, Roland, and Sheeri.
However, instead of the iPod (I got it after lunch, BTW) I was called on stage to get a Community Award, and the same was granted to Roland, Markus, and Rasmus (!!)
price giving

Looks quite useful. Now when somebody asks difficult questions, I can always consult the crystal ball. :)

Thanks to the MySQL Community for this wonderful surprise, and congratulations to Roland, Markus, and Rasmus!

(Pictures courtesy of Roland. Thanks)

Tuesday, April 25, 2006

Talk at the MySQL UC: Higher Order MySQL

From the highly unorthodox department, a speech about stored routines that create other routines in MySQL.

Higher Order MySQL at the MySQL Users Conference, 17:20, Ballroom C.

Get the source code and examples.

Friday, April 21, 2006

Advanced replication techniques in MySQL 5.x

OnLamp has just published an article I wrote about some interesting things you can do with MySQL 5.x and replication.
  • You can create an array of peer-to-peer nodes that are at the same time master and slave, without much worry about insertion conflicts, thanks to some server variables introduced in MySQL 5.0;
  • You can achieve automatic failover using a combination of federated tables (MySQL 5.0) and events (5.1)
The article is a proof of concept that using such techniques you can achieve your goals without help from external applications.

If you want to get your hands dirty, using the companion package MySQL Replication Playground you can try out the goodies described in the article without risking your valuable servers.

Comments welcome.

Introducing MySQL 5 Replication Playground

As promised when I talked about the MySQL Sandbox and as mentioned in this (very) recent article on replication, I have released a testing environment for replication, called the MySQL 5 Replication Playground.
It's a package that creates in one single server an array of four replicating nodes using MySQL 5.0 or 5.1. The purpose of this package is to help developers and administrators when they need to test applications involving replication. You don't need to use several boxes. One machine is enough. With just one instance of MySQL installed, the Replication Playground will install four data directories and it will create the necessary scripts to start, stop, and using the nodes.
The installation comes in two flavors: standard (i.e. one master and three slaves, as usual) and circular (where each node is at once master and slave, as explained in the above mentioned article).
Once you install it, you can play with it and test your failover procedures, without worrying about your valuable production data. The playground works with separated ports and sockets, and it's completely independent from any other MySQL installation.

The docs in the distribution package contain also some sample sessions with both the standard and the circular installation.

The package requires:
  • Linux, or FreeBSD (theoretically, it should work with any Unix flavor, but it has been tested only with Linux and FreeBSD)
  • MySQL 5.0 or 5.1
  • bash
  • tar
  • gzip
  • Perl (for the installation)
  • Optionally, you need the Perl DBI and DBD::mysql to run some test tools

Wednesday, April 19, 2006

Introducing MySQL Sandbox

Normal MySQL users are going through a flurry of announcements about new versions that make them salivate ath the thought of what can be done with these new goodies. In November, version 5.0 became generally available, thur ready for production, then version 5.1 entered beta.
Ah! It would be nice if I could just install the new versions and test them. Sometimes, though, you can't do that, because you don't have root access, or you have already an older MySQL server running.
For years, due to my consulting duties, I have maintained several non-conflicting, different versions of MySQL. I did that manually, using some scripts that I have developed and tuned over time. For me it is not a big hassle. I am used to the command line, I wrote the tools, I know what to take care of, it's easy. Not so for some of my co-workers, who need to use the same facilities but lack the same degree of confidence that I got with trial-and-error.
So finally I put together all I did for myself and transferred most of my own knowledge into a Perl script that can create a seamless installation of MySQl 5.0 or 5.1 without need of root access, and without disturbing (or being disturbed by) existing MySQL installations.
I called this tool the MySQL Sandbox and I put it on SourceForge.

With this package, achieving your goal of a separated testing installation is quite simple (provided that you are running Linux or some other Unix, that is):
  • Download the binaries for the version of MySQL you want to try, or follow Markus Popp's instructions and compile your own.
  • Unpack MySQL binaries in a convenient place (for the sake of this example, let's say you put it under $HOME/binaries/5.1.10)
  • Download the latest MySQL Sandbox package and unpack it.
  • Run the install program, saying where are the binaries
$ ./ --basedir=$HOME/binaries/5.1.10
The MySQL 5 Sandbox, version 1.1 19-Apr-2006
(C) 2006 Giuseppe Maxia, Stardata s.r.l.

installing with the following parameters:
basedir : /home/gmax/binaries/5.1.10
binbash : /bin/bash
conf_file :
datadir_from : archive
db_password : datacharmer
db_user : datacharmer
force : 0
home_directory : /home/gmax
install_version : 5.1
my_file :
operating_system_user : gmax
sandbox_directory : mysql_sandbox
sandbox_port : 3310
verbose : 0
do you agree? ([Y],n)
If you answer "Y", or just press ENTER, the sandbox will create a $HOME/mysql_sandbox directory, and a data directory under it, containing the minimum for your MySQL installation to work.
The destination directory will also contain some shell scripts to start, stop, and use the test server.
Optionally, you can also change the default configuration file by specifying --my_file={small|large|huge} . The sandbox installer will try to locate the sample files from the basedir you indicated, and will merge the basic parameters into your destination file (my.sandbox.cnf)
Once the installation is over, you go to the newly created directory, and start the server:
$ ./
~/binaries/5.1.10 ~/mysql_sandbox
sandbox server started
After that, using the new server is easy.
$ ./
Welcome to the MySQL monitor. Commands end with ; or \g.
Your MySQL connection id is 1 to server version: 5.1.10-beta-max

Type 'help;' or '\h' for help. Type '\c' to clear the buffer.

mysql [localhost] {datacharmer} ((none)) > exit
As you see, there is also a dedicated prompt that may remind you what you are using.
It has been tested in several Linux boxes. Ideally, it should work on every Unix box. Read the docs, or try
$ ./install --help

Happy testing!

However, that is not the end of it. More goodies are coming in the next days. Stay tuned.

Sunday, April 16, 2006

SQL Easter egg

There is a tentative Obfuscated SQL contest with one entry by Kai Voigt.
SELECT CONCAT(CONV(536,8,20), LPAD(EXPORT_SET(1,'Y','N','',1), 3, "P"), CHAR(32), HEX(234), UNHEX(594939469*POW(3,2)))
Not bad, but ... SQL without data ? Doesn't sound right.
Here's my take (requires MySQL 4.1 or later):
drop table if exists complex;
drop table if exists simple;
CREATE TABLE complex ( simple char(2), complex char(1)) ;
CREATE TABLE simple ( complex char(2), simple char(1));

INSERT INTO complex VALUES ('0','7'),('1','6'),('2','6'),('3','6'),('4','2'),
INSERT INTO simple VALUES ('0','4'),('1','F'),('2','5'),('3','8'),('4','0'),
set @complex = sqrt(sqrt(0x19a1));
set @simple = sqrt(sqrt(sqrt(0x290D741)));
select group_concat(unhex(concat(simple,complex))
order by complex.non_simple separator '' )
from (select simple ^ @complex non_simple, complex simple from complex) simple natural join
(select complex ^ @simple non_simple, simple complex from simple) complex ;


Sunday, April 09, 2006

Sorting data by set of keys

This seems to be a popular problem, since I saw it twice in the past few weeks in two different newsgroups. Somebody complains that, having query with a set of keys like this
SELECT * from mytable where id IN (200, 2 ,100)
they get the results in a order that ius different from the one they specified. For example, they may get something like
id in (200,2,100);
| id | contents |
| 2 | b |
| 100 | aa |
| 200 | bb |
One of the posters complained that the result should come in the specified order [200,2,100], and that MySQL was arbitrarily sorting its resultset.
When I see such requests, I usually explain that there are two misconceptions. The first being that MySQL sorts results without asking. That it does not do, because a DBMS engine is basically lazy by design, and it won't do anything unless explicitly asked for. The second is that you are asking for a sort order in your set of keys. Such list is just an indication of which keys to consider for filtering the results, and it has no influence at all on ordering. If you want ordering, you need to say so explicitly, using the ORDER BY clause.
Once I clarified what the problem is, let's see the solutions.
You can sort it on-the-fly, if your values are reasonably few
id in (200, 2, 100)
order by
case id
when 200 then 1
when 2 then 2
when 100 then 3
end ;
| id | contents |
| 200 | bb |
| 2 | b |
| 100 | aa |
This solution looks like a hack, and in fact it can negatively affect performance, and it is difficult to handle when you need to change the sort order. The best way is to use a support table providing the required sort order.
create table sorting_table (
sort_order int not null auto_increment primary key,
fk_id int,
key (fk_id)
# here we insert the values in the order we want.
# the auto incremented key will insure that this is the correct one
insert into sorting_table (fk_id) values (200), (2), (100);
select * from sorting_table;
| sort_order | fk_id |
| 1 | 200 |
| 2 | 2 |
| 3 | 100 |
Now to get the wanted order we use a join between the main table and the secondary one.
inner join sorting_table on (id=fk_id)
id in (200,2, 100)
order by
sort_order ;
| id | contents |
| 200 | bb |
| 2 | b |
| 100 | aa |
This is a much better solution, which offers flexibility and efficiency at the same time.

Dumping MySQL information schema

I have been invited to join the O'Reilly weblogs on databases.
Today I gave my first contribution, with a piece on dumping MySQL information schema contents.

Sunday, April 02, 2006

Measuring replication speed

I am writing an article about some advanced replication features (coming soon), and I wanted to measure the speed of each specific architecture I am working with.
There seem to be no builtin MySQL solution for this particular problem, and thus I am using a hand made metrics tool, inspired by something that Jeremy Zawodny suggested in his High Performance MySQL a few years ago (see the relevant chapter on replication with code).
The naive method would be to set a timestamp in a master table, and to measure the same record when it shows up in the slave. Unfortunately, (but correctly, I have to say!) this does not work, because the binary log includes information on the current timestamp, so that master and slave in the end have exactly the same contents.
Using a trigger in MySQL 5.0 seems promising, because you can set the timestamp tothe value of SYSDATE(), thus showing the different insertion times in master and slave. However, MySQL imestamps precision is limited to seconds. Therefore, if I insert a record at 12:00:00.9999 and the slave receives it at 12:00:01.0001, MySQL will record a difference of 1 second, even though in this case the difference would be just a couple of milliseconds.

With this in mind, I worked on Zawodny suggestion, which was still dealing with seconds, to imrove the method and measure the performance of a replication system with a much better accuracy (possibly microseconds).

The schema works as follows (see the flow chart):

Get the system time in terms of seconds and microseconds (I am using Perl with the Time::HiRes module, but any major language has a corresponding feature). Insert that time in a table on the master, measuring also the time spent for the insertion operation.
Immediately after, start looping on the slave to get that same record. When you do it, get again the system time (with microseconds precision) and subtract the time you got from the table.
For better precision subtract the time you used for inserting and for fetching, and you get the bare replication time.

Here is an example, using a record of 1000 bytes, in a loop that increases the size of the record by 1000 bytes at each step.
0    41     5   1143983120       992916   1143983120       997036
1    41     5   1143983121       207218   1143983121       211084
2    41     5   1143983121       420654   1143983121       424630
3    41     5   1143983121       634802   1143983121       638909
4    41     5   1143983121       849051   1143983121       853521
5    41     5   1143983122        65003   1143983122        67892
6    41     5   1143983122       279944   1143983122       282933
7    41     5   1143983122       493895   1143983122       498320
8    41     5   1143983122       710443   1143983122       715032
9    41     5   1143983122       927867   1143983122       932013
10    41     5   1143983123       145376   1143983123       149648

This is the raw output used for debugging. The first colum is the step. The second is the ID retrieved from the record, the third one is the sequence number (I inserted 5 records for each steps, and asked to fetch the record with sequence no. 5).
The fourth and fifth columns are the system time that was stored in the table. The remaining two columns are the system time as recorded at fetch time.
With the above data, we can produce a listing of the actual raplication times, in human-readable format.
loop data size master insert slave retrieval total repl. time bare time
---- --------- ------------- --------------- ---------------- ---------
1      1000      0.001655        0.000859         0.004120  0.001606
2      1000      0.001643        0.001268         0.003866  0.000955
3      2000      0.001505        0.000850         0.003976  0.001621
4      3000      0.001604        0.000849         0.004107  0.001654
5      4000      0.001943        0.000851         0.004470  0.001676
6      5000      0.001853        0.000981         0.002889  0.000055
7      6000      0.001964        0.000968         0.002989  0.000057
8      7000      0.003285        0.001081         0.004425  0.000059
9      8000      0.001431        0.000851         0.004589  0.002307
10      9000      0.003076        0.001012         0.004146  0.000058
11     10000      0.001282        0.001600         0.004272  0.001390

So the average replication time is, in this case, 0.001040 seconds.
For this test, I was using a sandbox environment, where both master and slave are in the same server. Thus there is some slight overhead due to the fact that one CPU is handling two instances of MySQL, and the same disk is hosting two logs (binary on the master, relay-log on the slave) in addition to the actual tables.
Using a real production replication, these times go down to an average of about 0.000500 seconds. It depends on several factors, from the speed of your networking equipment to the sheer power of your boxes.

Anyway, this is a tool that can be useful sometimes. You can get the source code from MySQL Forge snippets.

Update Since the Forge is being decomissioned, I add the source code here.

use strict;
use warnings;
use Data::Dumper;
use DBI;
use Time::HiRes qw/ usleep gettimeofday tv_interval/;
use English qw( -no_match_vars );

my $username1 = 'user1';
my $password1 = 'user2';
my $username2 = 'pass1';
my $password2 = 'pass2';
my $host1     = 'host_IP1';
my $host2     = 'host_IP2';
my $port1     = '3306';
my $port2     = '3306';

my $dbh1=DBI->connect("dbi:mysql:test;host=$host1;port=$port1",
                $username1, $password1,
                {RaiseError => 1})
         or die "Can't connect: $DBI::errstr\n";

my $dbh2=DBI->connect("dbi:mysql:test;host=$host2;port=$port2",
                $username2, $password2,
                {RaiseError => 1})
         or die "Can't connect: $DBI::errstr\n";

my $loops                =     10; # how many times we loop (with size increase)
my $num_of_inserts       =      5; # how many records we insert for each loop
my $initial_blob_size    =  1_000; # how big is the record we start with
my $replica_db           = 'test'; # which database we use for testing

my $master_dbh = $dbh1;
my $slave_dbh = $dbh2;

my ( $exists_db ) = $master_dbh->selectrow_array(qq{SHOW DATABASES LIKE '$replica_db'});
unless ($exists_db) {
    eval {$master_dbh->do(qq{CREATE DATABASE $replica_db}) };
    if ( $EVAL_ERROR ) {
        die "execution error $DBI::errstr\n";

# creating the measurement table
eval {
    $master_dbh->do( qq{
        CREATE DATABASE IF NOT EXISTS $replica_db});
    $master_dbh->do( qq{
        USE $replica_db } );
    $master_dbh->do( qq{
        DROP TABLE IF EXISTS replica_speed });
    $master_dbh->do( qq{
       CREATE TABLE replica_speed (
        id int(11) NOT NULL auto_increment,
        insert_sequence int not null,
        seconds bigint(20) default NULL,
        microseconds bigint(20) default NULL,
        ts timestamp(14) NOT NULL,
        big_one longtext,
        PRIMARY KEY  (`id`),
        KEY insert_sequence (insert_sequence)
    } );
if ($EVAL_ERROR) {
    die "table creation error $DBI::errstr\n";

# give some time to the table creation to get replicated
my $insert_query = qq{
    INSERT INTO $replica_db.replica_speed
        (insert_sequence, seconds, microseconds, big_one)
       VALUES ( ?, ?, ?, ?) };
my $retrieve_query = qq{
    SELECT seconds, microseconds, id, insert_sequence
    FROM $replica_db.replica_speed
    WHERE insert_sequence = ?
my $slave_sth = $slave_dbh->prepare($retrieve_query);

# checking max_allowed_packet to make sure that we are not
# exceeding the limits
my ( undef, $master_max_allowed_packet) = $master_dbh->selectrow_array(
        qq{ SHOW VARIABLES LIKE "max_allowed_packet" } );

my ( undef, $slave_max_allowed_packet) = $slave_dbh->selectrow_array(
        qq{ SHOW VARIABLES LIKE "max_allowed_packet" } );

my $max_allowed_packet = $master_max_allowed_packet;
if ( $slave_max_allowed_packet < $master_max_allowed_packet) {
    $max_allowed_packet = $slave_max_allowed_packet;
my @results     = ();

for my $loopcount (0 .. $loops )
    # let's start with an empty table
    $master_dbh->do( qq{ TRUNCATE $replica_db.replica_speed } );
    my $size   = $initial_blob_size * ($loopcount || 1);
    if ($size > $max_allowed_packet) {
        $size  = $max_allowed_packet - 1000;
    my $master_insert_time  = 0.0;
    my $big_blob            = 'a' x $size;

    # inserting several records in the master
    for my $sequence (1 .. $num_of_inserts ) {
        my ( $secs, $msecs ) = gettimeofday();
        $master_dbh->do($insert_query, undef, $sequence, $secs, $msecs, $big_blob);
        $master_insert_time = tv_interval( [$secs, $msecs],  [gettimeofday()]);
    my $replication_delay     = 0;
    my $total_retrieval_time  = 0;
    my $baredelay             = undef;
    # fetching data from the slave
    while ( ! $replication_delay ) # waiting for data to arrive from master to slave
        my $retrieval_start_time = [gettimeofday()];
        $slave_sth->execute( $num_of_inserts);
        my $info                = $slave_sth->fetchrow_arrayref();
        my $retrieval_stop_time = [gettimeofday()];
        my $retrieval_time      = 0.0;
        $retrieval_time         = tv_interval(
        next RETRIEVAL unless $info->[0];
        # retrieval time is counted only after a successful fetch
        $total_retrieval_time   += $retrieval_time;
        $replication_delay      = tv_interval( [$info->[0], $info->[1]], $retrieval_stop_time);
        $baredelay              = $replication_delay - $total_retrieval_time - $master_insert_time;
        printf "%4d %5d %5d %12d %12d %12d %12d\n",
            $loopcount, $info->[2], $info->[3] , $info->[0] , $info->[1] ,
            $retrieval_stop_time->[0], $retrieval_stop_time->[1];

    push @results,
            data_size             => $size,
            master_insert_time    => $master_insert_time,
            slave_retrieval_time  => $total_retrieval_time,
            replication_time      => $replication_delay,
            bare_replication_time => $baredelay,

# displaying results
my @header_sizes = qw(4 9 13 15 16 9);
my @headers = ('loop', 'data size', 'master insert', 'slave retrieval', 'total repl. time', 'bare time');
printf "%s %s %s %s %s %s\n" , @headers;
printf "%s %s %s %s %s %s\n" , map { '-' x $_ } @header_sizes;
my $count = 0;
for my $res (@results)
    printf "%4d %9d %13.6f %15.6f %16.6f %9.6f\n" , ++$count,
        map { $res->{$_} }
            qw/data_size master_insert_time slave_retrieval_time replication_time bare_replication_time/;

Comments welcome.
